FiT » BRAKE SHOE » FT1098 Feedback Information NEW!

Image Of FT1098
Specification
Radius 107.5
Width 45
Thickness 3
Pcs In Set 2
Owner Number
ANCHI A60040
ATE 03.0137-3007.2
Blue Print ADT34175
BOSCH 0986487727
DANAHER DBS10152
DANAHER DBS10152A
DELPHI LS2053
FENOX BP53173
FERODO FSB 4120
FMSI S850-1580
LYNXauto BS-7531
MASUMA MK-2504
MASUMA MK-2513
MILES E310349
MINTEX MFR615
NIPPARTS N3502092
STELLOX 000 529-SX
TEXTAR 91066100
TOYOTA 06540-60031
TOYOTA 46540-0K010
TOYOTA 46540-60010
TOYOTA 46540-60020
TOYOTA 46540-60030
TOYOTA 46540-60060
TOYOTA 46550-0K010
TOYOTA 46550-60020
TOYOTA 46550-60030
TOYOTA 46550-60031
TOYOTA 46550-60040
TOYOTA 46550-60050
TOYOTA 46550-60070
TOYOTA 46580-60020
TOYOTA 46580-60030
TOYOTA 46580-60060
TOYOTA 46590-0K010
TRW GS 8716
ZEKKERT BK-4183
Copyright © 2025
Years Eng Vol Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
TOYOTA   »   Land Cruiser Prado
04.96~11.02 3000 1KD-FTV KDJ90L FR0241V FP1436FP0436 FR0328V FT1184FP0606 FT1098
04.96~10.02 3000 1KZ-TE KZJ90L FR0241V FP0436FP1436 FR0328V FT1184FP0606 FT1098
04.96~10.02 3400 5VZ-FE VZJ90W FR0241V FP0436 FR0328V FP0606 FT1098
04.95~11.02 3000 1KZ-TE KZJ95W FR0241V FP0436 FR0328V FP0606 FT1098
04.96~10.02 3400 5VZ-FE VZJ95R FR0241V FP0436FP1436 FR0328V FT1184FP0606 FT1098
08.00~11.02 3000 1KD-FTV KDJ95W FR0241V FP1436FP0436 FR0328V FP0606 FT1098
08.00~09.02 3000 1KD-FTV KDJ95L FR0241V FP1436FP0436 FR0328V FP0606 FT1098
04.96~11.02 2700 3RZ-FE RZJ95W FR0241V FP0436FP1436 FR0328V FT1184FP0606 FT1098
11.84~12.96 2400 2LT LJ70 FR0951FR0252V FP0436FP0137 FR0328V FT0764FT1184FP0606 FT1098
04.96~08.00 3000 1KZ-TE KZJ90W FR0241V FP0436 FR0328V FP0606 FT1098
04.96~08.00 3000 1KZ-TE KZJ90R FR0241V FP0436FP1436 FR0328V FT1184FP0606 FT1098
04.90~05.93 2400 2L-TE LJ71G FR0252V FP0209 FR0328V FP0606 FT1098
04.97~09.02 2700 3RZ-FE RZJ95R FR0241V FP0436FP1436 FR0328V FT1184FP0606 FT1098
04.96~11.02 2700 3RZ-FE RZJ95L FR0241V FP0436FP1436 FR0328V FT1184FP0606 FT1098
08.00~11.02 3000 1KD-FTV KDJ90W FR0241V FP1436FP0436 FR0328V FP0606 FT1098
01.90~05.96 2400 2L-TE LJ78W FR0252V FP0436FP1436 FR0328V FP0606 FT1098
05.93~04.96 3000 1KZ-TE KZJ78W FR0252V FP0436FP1436 FR0328V FP0606 FT1098
04.96~10.03 3400 5VZ-FE VZJ95L FR0241V FP0436FP1436 FR0328V FP0606 FT1098
08.00~09.02 3000 1KD-FTV KDJ95R FR0241V FP1436FP0436 FR0328V FP0606 FT1098
04.90~05.93 2400 2L-TE LJ78G FR0252V FP1436FP0716 FR0328V FP0606 FT1098
05.93~04.96 3000 1KZ-TE KZJ71G FR0252V FP0436FP1436 FR0328V FP0606 FT1098
04.96~09.02 3000 1KZ-TE KZJ95L FR0241V FP0436FP1436 FR0328V FP0606 FT1098
04.96~11.02 3400 5VZ-FE VZJ95W FR0241V FP1436FP0436 FR0328V FP0606 FT1098
TOYOTA   »   Land Cruiser Prado 120
09.02~08.09 3000 1KD-FTV KDJ120L FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.09 4000 1GR-FE GRJ120W FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.09 3000 1KZ-TE KZJ120R FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.09 3000 5L-E LJ125 FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.09 3000 5L-E LJ120L FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.09 4000 1GR-FE GRJ121R FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.05 3400 5VZ-FE VZJ121 FR0441V FP0976 FR0328V FP0606 FT1098
09.02~08.09 2700 3RZ-FE RZJ125 FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.09 2700 3RZ-FE RZJ120 FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.09 4000 1GR-FE GRJ125L FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.09 3000 5L-E LJ120R FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.09 4000 1GR-FE GRJ120L FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.09 4000 1GR-FE GRJ120R FR0332V FP0976 FR0328V FP0606 FT1098
08.04~08.09 2700 2TR-FE TRJ120L FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.09 2700 2TR-FE TRJ120 FR0332V FP0976 FR0328V FP0606 FT1098
11.02~08.09 3000 1KD-FTV KDJ120W FR0332V FP0976 FR0328V FP0606 FT1098
08.04~08.09 3000 1KD-FTV KDJ120R FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.05 3400 5VZ-FE VZJ120W FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.05 3400 5VZ-FE VZJ125 FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.09 3000 1KZ-TE KZJ120L FR0332V FP0976 FR0328V FP0606 FT1098
08.04~08.09 2700 2TR-FE TRJ120R FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.09 2700 3RZ-FE RZJ120R FR0332V FP0976 FR0328V FP0606 FT1098
09.02~08.04 2700 3RZ-FE RZJ120L FR0332V FP0976 FR0328V FP0606 FT1098
08.04~08.09 2700 2TR-FE TRJ125L FR0332V FP0976 FR0328V FP0606 FT1098
TOYOTA   »   Land Cruiser
01.90~08.95 4200 1HD-#T HDJ80L FR0200VFR0176V FP0502 FR0959VFR0269V FP0606FT2131FT1173 FT1098
01.90~01.07 4200 1H-Z HZJ79 FR0707V FP0772 FR1103V FT2131FT1173FP0606 FT1098
01.90~01.98 4200 1H-Z HZJ80L FR0200V FP0502 FR0959V FP0606FT2131FT1173 FT1098
01.07~ 4500 1VD-FTV VDJ79R FR0707V FP0772 FR1103V FT2131FT1173FP0606 FT1098
01.90~12.01 4200 1H-Z HZJ73V FR0252V FP0436FP1436 FR0269V FP0606FT2131FT1173 FT1098
01.90~08.99 4200 1H-Z HZJ73HV FR0252V FP1436 FR0269V FP0606 FT1098
08.98~ 4200 1H-Z HZJ78R FR0707V FP0772 FR1103V FT2131FT1173FP0606 FT1098
08.12~ 4000 1GR-FE GRJ78L FR0707V FP0772 FR1103V FP0606FT2131FT1173 FT1098
01.90~01.95 4200 1HD-T HDJ81V FR0200VFR0176V FP0502 FR0269V FP0606 FT1324FT1098
01.07~ 4200 1H-Z HZJ76L FR0707V FP0772 FR1103V FT2131FT1173FP0606 FT1098
01.90~09.92 4000 3F-E FJ80G FR0200V FP0502 FR0959V FP0606 FT1098
01.90~09.92 4000 3F-E FJ80L FR0200V FP0502 FR0959V FP0606FT2131FT1173 FT1098
01.90~09.92 4000 3F-E FJ80R FR0200V FP0502 FR0959V FP0606FT2131FT1173 FT1098
01.07~ 4000 1GR-FE GRJ79L FR0707V FP0772 FR1103V FT2131FT1173FP0606 FT1098
01.07~ 4000 1GR-FE GRJ79R FR0707V FP0772 FR1103V FP0606FT2131FT1173 FT1098
01.90~01.95 4200 1H-Z HZJ80R FR0200V FP0502 FR0959VFR0269V FT2131FT1173FP0606 FT1098FT1324
01.07~ 4500 1VD-FTV VDJ78R FR0707V FP0772 FR1103V FT2131FT1173FP0606 FT1098
01.90~08.95 4200 1HD-#T HDJ80R FR0200VFR0176V FP0502 FR0269VFR0959V FT2131FT1173FP0606 FT1098
01.90~01.95 4200 1H-Z HZJ81 FR0200VFR0176V FP0502 FR0269V FT2131FT1173FP0606 FT1098FT1324
08.99~08.04 4200 1H-Z HZJ76K FR0707V FP0772 FR1103V FP0606FT2131FT1173 FT1098
08.99~08.04 4200 1H-Z HZJ76V FR0707V FP0772 FT2131FT1173 FT1098
04.90~08.99 4200 1H-Z HZJ77HV FR0252V FP0436FP1436 FR0269V FT2131FT1173FP0606 FT1098
08.99~09.17 4200 1H-Z HZJ79L FR0707V FP0772 FR1103V FP0606FT2131FT1173 FT1098
08.14~07.15 4000 1GR-FE GRJ76K FR0707V FP0772 FR1103V FP0606 FT1098
08.14~05.16 4000 1GR-FE GRJ79K FR0707V FP0772 FR1103V FP0606 FT1098
08.98~07.09 4500 1FZ-FE FZJ79L FR0707V FP0772 FR1103V FT2131FT1173FP0606 FT1098
01.07~ 4200 1H-Z HZJ76R FR0707V FP0772 FR1103V FP0606FT2131FT1173 FT1098
08.99~ 4200 1H-Z HZJ79R FR0707V FP0772 FR1103V FP0606FT2131FT1173 FT1098
01.07~ 4000 1GR-FE GRJ71L FR0707V FP0772 FR1103V FT2131FT1173FP0606 FT1098
01.90~09.23 4200 1H-Z HZJ71L FR0707V FP0772 FR1103V FT2131FT1173FP0606 FT2131FT1173FT1098
01.07~09.23 4500 1VD-FTV VDJ76R FR0707V FP0772 FR1103V FP0606FT2131FT1173 FT1098
01.86~01.97 3000 1KZ-TE KZJ71W FR0252V FP0436FP1436 FR0328V FP0606 FT1098
05.22~ 4500 1VD-FTV VDJ79L FR0707V FP0772 FT1098
08.98~ 4200 1H-Z HZJ78L FR0707V FP0772 FR1103V FP0606FT2131FT1173 FT1098
TOYOTA   »   FJ Cruiser
11.10~01.18 4000 1GR-FE GSJ15W FR0551V FP0976 FR0658V FP0606 FT1098
07.07~12.22 4000 1GR-FE GSJ15L FR0551V FP0976 FR0328V FP0606 FT1098
01.06~07.14 4000 1GR-FE GSJ10L FR0551V FP0976 FR0328VFR0658V FP0606 FT1098
TOYOTA   »   Land Cruiser Prado 150
06.15~12.23 2800 1GD-FTV GDJ155 FR0541V FP0976 FR0658V FP0606 FT1098
06.15~12.23 2800 1GD-FTV GDJ150 FR0541V FP0976 FR0658V FP0606 FT1098
08.09~06.15 4000 1GR-FE GRJ150W FR0541V FP0976 FR0658V FP0606 FT1098
08.09~12.23 2700 2TR-FE TRJ150W FR0541V FP0976 FR0658V FP0606 FT1098
08.09~12.23 2700 2TR-FE TRJ150L FR0541V FP0976 FR0658V FP0606 FT1098
06.09~12.23 4000 1GR-FE GRJ150L FR0541V FP0976 FR0658V FP0606 FT1098
08.09~08.17 3000 1KD-FTV KDJ150L FR0541V FP0976 FR0658V FP0606 FT1098
08.09~08.17 3000 1KD-FTV KDJ150R FR0541V FP0976 FR0658V FP0606 FT1098
08.17~07.20 3000 1KD-FTV KDJ150L FR0541V FP0976 FR0658V FP0606 FT1098
08.09~06.15 4000 1GR-FE GRJ151W FR0541V FP0976 FR0658V FP0606 FT1098
08.09~12.23 3000 5L-E LJ150 FR0541V FP0976 FR0658V FP0606 FT1098
08.13~07.26 3000 1KD-FTV KDJ155L FR0541V FP0976 FR0658V FP0606 FT1098
06.15~12.23 2800 1GD-FTV GDJ151W FR0541V FP0976 FR0658V FP0606 FT1098
06.15~12.23 2800 1GD-FTV GDJ150L FR0541V FP0976 FR0658V FP0606 FT1098
06.15~12.23 2800 1GD-FTV GDJ150R FR0541V FP0976 FR0658V FP0606 FT1098
TOYOTA   »   4 Runner
11.02~08.09 4000 1GR-FE GRN210 FR0551VFR0332V FP0976 FR0328V FP0606 FT1098
11.02~09.05 3000 1KZ-TE KZN215L FR0551V FP0976 FR0328V FP0606 FT1098
11.02~08.09 4000 1GR-FE GRN215L FR0551VFR0332V FP0976 FR0328V FP0606 FT1098
08.09~08.19 4000 1GR-FE GRN285L FR0541V FP0976 FR0658V FP0606 FT1098
08.09~05.15 4000 1GR-FE GRN280L FR0541V FP0976 FR0658V FP0606 FT1098
11.09~08.11 2700 2TR-FE TRN280L FR0541V FP0976 FR0658V FP0606 FT1098
08.02~05.20 4700 2UZ-FE UZN215 FR0332V FP0976 FR0328V FP0606 FT1098
08.02~08.09 4700 2UZ-FE UZN210 FR0551VFR0332V FP0976 FR0328V FP0606 FT1098
08.01~12.04 3000 1KZ-TE KZN205L FR0551V FP0976 FR0328V FP0606 FT1098
TOYOTA   »   Fortuner
01.16~ 2700 2TR-FE TGN166R FR1072V FR0658V FT1081FP0606FP1391 FT1098
07.15~ 2800 1GD-FTV GUN156R FR1072V FR0658V FP0606FP1391 FT1098
05.16~ 2700 2TR-FE TGN156R FR1072V FR0658V FT1081FP0606FP1391 FT1098
07.15~ 2800 1GD-FTV GUN156L FR1072V FR0328V FP1391FP0606 FT1098
01.16~ 2700 2TR-FE TGN166L FR1072V FR0658VFR0328V FT1081FP0606FP1391 FT1098
12.15~ 4000 1GR-FE GGN155L FR1072V FP0976 FR0328V FT1081FP1391 FT1098
01.16~ 2400 2GD-FTV GUN155R FR1072VFR0430V FR0658VFR0328V FP0606FP1391 FT1098
01.16~ 2700 2TR-FE TGN156L FR1072V FR0658VFR0328V FT1081FP0606FP1391 FT1098
07.20~ 2400 2GD-FTV GUN166L FR1072V FR0328V FP1391 FT1098
07.15~ 2400 2GD-FTV GUN165L FR1072V FR0328V FT1081FP1391 FT1098
03.16~ 2400 2GD-FTV GUN166R FR0430V FR0658V FP1391FP0606FT1081 FT1098
07.15~04.21 2400 2GD-FTV GUN165R FR0430V FR0658V FP0606 FT1098
08.22~ 2400 2GD-FTV GUN155L FR1072VFR0430V FR0658VFR0328V FP0606FP1391 FT1098
03.16~09.17 3000 1KD-FTV KUN156R FR0430V FR0658V FP0606 FT1098
TOYOTA   »   Hilux Surf
08.04~08.09 2700 2TR-FE TRN215W FR0551V FP0976 FR0328V FP0606 FT1098
10.02~08.04 2700 3RZ-FE RZN210W FR0551V FP0976 FR0328V FP0606 FT1098
08.05~08.09 4000 1GR-FE GRN215W FR0551V FP0976 FR0328V FP0606 FT1098
08.04~07.09 2700 2TR-FE TRN210W FR0551V FP0976 FR0328V FP0606 FT1098
11.02~08.05 3400 5VZ-FE VZN210W FR0551V FP0976 FR0328V FP0606 FT1098
11.02~08.04 2700 3RZ-FE RZN215W FR0551V FP0976 FR0328V FP0606 FT1098
11.02~08.05 3000 1KD-FTV KDN215W FR0551V FP0976 FR0328V FP0606 FT1098
11.02~08.05 3400 5VZ-FE VZN215W FR0551V FP0976 FR0328V FP0606 FT1098
TOYOTA   »   Sequoia
09.00~12.07 4700 2UZ-FE UCK45 FP0772FP0976 FR0328V FP0606 FT1098
LEXUS   »   GX460
11.09~ 4600 1UR-FE URJ150L FR0541V FP0976 FR0658V FP0606 FT1098
LEXUS   »   GX470
11.02~08.09 4700 2UZ-FE UZJ120 FR0332V FP0976 FR0328V FP0606 FT1098
LEXUS   »   GX400
06.12~11.17 4000 1GR-FE GRJ158 FR0541V FP0976 FR0658V FP0606 FT1098
