| Specification | |
|---|---|
| Type | Vented |
| Outter Ø | 280 |
| Num. of holes | 5 |
| Disc Thickness (Max) | 23 |
| Height | 44.2 |
| Centering Diameter | 69 |
| Pitch Circle Ø | 114.3 |
| Front/Rear | Front |
| Drum Ø: | 143 |
| Hole Ø: | 12.6 |
| Disc Thickness (Min) | 21.4 |
| Structure Material | G3000 |
| Alternatives | |
|---|---|
| FiT | FR0666V |
| Owner | Number |
|---|---|
| A.B.S. | 18202 |
| AISIN | R6F988S |
| ASHUKI | I032-38 |
| Blue Print | ADG043175 |
| BOSCH | 0 986 479 A12 |
| DENCKERMANN | B130699 |
| Febi | 108394 |
| FERODO | DDF2187C |
| HI-Q | SD1071 |
| HI-Q | SD1071B |
| HYUNDAI | 51712-2V000 |
| HYUNDAI | 51712-3X000 |
| HYUNDAI | 51712M0000 |
| HYUNDAI / KIA | 51712-3Y000 |
| HYUNDAI / KIA | 51712-J1500 |
| HYUNDAI / KIA | 517123X000 |
| KIA | 51712-2V000 |
| KIA | 51712-D8000 |
| LYNXauto | BN-1536 |
| MILES | K001611 |
| MILES | K201609 |
| NIPPARTS | N3300536 |
| NISSHINBO | ND6028K |
| NK | 203445 |
| SANGSIN | SD1071 |
| SASIC | 6106228 |
| SWAG | 33107281 |
| TEXTAR | 92243103 |
| TRADEX | TBD1153 |
| TRW | DF7966 |
| ZEKKERT | BS-5657 |
| ZEKKERT | BS-5657B |
| ZIMMERMANN | 285352720 |
| ZIMMERMANN | 285352752 |
| Copyright © 2025 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.11~03.15 | 1600 | G4FG | D351 5DR RHD | FR0654V | FP1543 | FR0655 | FP1313 | |
| 09.11~03.15 | 1800 | G4NB | PA512 RHD | FR0654V | FP1543 | FR0655 | FP1313 |
| 07.13~09.15 | 1600 | G4FG | MD | FR0654V | FP1543 | FR0655 | FP1313 | |
| 08.13~08.15 | 1600 | D4FB | MD | FR0654V | FP1543 | FR0655 | FP1313 | |
| 07.13~09.15 | 2000 | G4NA | MD | FR0654V | FP1543 | FR0655 | FP1313 | |
| 07.13~09.15 | 1800 | G4NB | MD | FR0654V | FP1543 | FR0655 | FP1313 | |
| 01.14~01.16 | 1800 | G4NB | PSDA14 US | FR0654V | FP1543 | FR0655 | FP1313 |
| 01.10~01.15 | 1600 | G4FG | PSD11 RHD | FR0654V | FP1543 | FR0655 | FP1313FT1076 | |
| 09.11~07.13 | 1800 | G4NB | PSD11 LHD | FR0654V | FP1543 | FR0655 | FT1076FP1313 | |
| 01.10~12.13 | 1600 | G4FG | PSD11 LHD | FR0654V | FP1543 | FR0655 | FP1313FT1076 | |
| 08.10~08.13 | 1600 | G4FD | PSD11 LHD KDOM | FR0654V | FP1543 | FR0655 | FP1313 |
| 01.12~01.15 | 1600 | G4FD | TC61D | FR0654V | FP1543 | FR0655 | FP1313 | |
| 01.12~01.15 | 1600 | G4FG | TC61C | FR0654V | FP1543FP1412 | FR0655 | FP1313 | |
| 01.15~02.18 | 1600 | G4FD | TC6AD | FR0654V | FP1543 | FR0655 | FP1313 | |
| 03.11~01.15 | 1600 | G4FD | TE61D | FR0654V | FP1543FP1412 | FR0655 | FP1313 |
| 08.16~05.21 | 1600 | G4FG | M017 RU | FR0654VFR0458V | FP0001 | FR0655FR1309 | FP1157 | |
| 03.20~10.21 | 2000 | G4NA | M017 RU | FR0654VFR0458V | FP0001 | FR0655FR1309 | FP1157 |
| 09.15~07.19 | 1600 | G4FG | PF216 RHD | FR0654V | FP1912 | FR0655 | FT1076FP1313 | |
| 09.15~07.19 | 2000 | G4NA | AD | FR0654V | FP1912 | FR0655 | FP1313 | |
| 09.15~07.19 | 1600 | D4FB | AD | FR0654V | FP1912 | FR0655 | FP1313 | |
| 09.15~07.19 | 1600 | D4FB | RPF216 | FR0654V | FP1912 | FR0655 | FT1076FP1313 | |
| 09.15~07.19 | 1600 | L4FA | PF216 | FR0654V | FP1912 | FR0655 | FT1076FP1313 | |
| 09.15~07.19 | 1600 | G4FG | PF216 LHD | FR0654V | FP1912 | FR0655 | FP1313 |
| 08.18~08.20 | 1600 | G4FG | PF219 RHD | FR0654V | FP1912 | FR0655 | FT1076FP1313 | |
| 08.18~08.20 | 2000 | G4NH | AD | FR0654V | FP1912 | FR0655 | FT1076FP1313 | |
| 08.18~08.20 | 2000 | G4NA | PF219 RHD | FR0654V | FP1912 | FR0655 | FT1076FP1313 | |
| 08.18~08.20 | 1600 | G4FM | PF219 LHD KDOM | FR0654V | FP1912 | FR0655 | FP1313 |
| 04.19~ | 1600 | G4FM | PSN19 RHD | FR0654V | FR0655 | FP1313 | ||
| 04.19~ | 1600 | G4FG | PSN19 RHD | FR0654V | FR0655 | FP1313 | ||
| 06.22~ | 1000 | G3LC | PSP22 RHD | FR0654V | FT1076 | |||
| 04.19~ | 1600 | G4FG | PSN19 LHD CHL | FR0654V | FR0655 | FP1313 | ||
| 10.18~06.22 | 1000 | G3LC | PSP19 RHD | FR0654V | FT1076 | |||
| 04.19~ | 1600 | G4FM | PSN19 US | FR0654V | FR0655 | FP1313 |
| 06.17~ | 1600 | D4FB | PJ918 LHD | FR0654V | FP0001 | FR1074 | FP1157 | |
| 09.20~ | 2000 | G4NS | PJ921 LHD | FR0654V | FP0001 | FR0655 | FP1157 | |
| 09.20~ | 1000 | G3LE | PJ921 RHD | FR0654V | FP0001 | FR0655 | FP1157 |
| 09.15~ | 1600 | G4FG | AD LHD PR | FR0654V | FP1912 | FR0655 | FT1076FP1313 | |
| 01.16~02.19 | 2000 | G4NH | PF316 US | FR0654V | FP1912 | FT1076 | ||
| 02.19~ | 2000 | G4NH | PF319 MEX | FR0654V | FP1912 | FR0655 | FP1313 | |
| 08.18~08.20 | 1600 | G4FG | PF219 LHD | FR0654V | FP1912 | FR0655 | FP1313 | |
| 01.16~02.19 | 2000 | G4NH | PF216 US | FR0654V | FP1912 | FT1076 |
| 03.12~08.15 | 1400 | G4FA | PA212 HB LHD | FR0654V | FP1543 | FR0655 | ||
| 03.12~07.15 | 1600 | G4FD | PA212 WGN LHD | FR0654V | FP1543 | FR0655 | ||
| 03.12~07.15 | 1600 | G4FG | PA212 HB LHD | FR0654V | FP1543 | FR0655 | ||
| 03.12~07.15 | 1600 | G4FD | PA212 HB LHD | FR0654VFR0653V | FP1543FP1412FP1827 | FR0667FR0655 | FP1313 |
| 08.20~ | 1500 | G4FL | PSX21 RHD | FR0654V | FT1076 | |||
| 08.20~ | 1000 | G3LC | PSX21 | FR0654V | FT1076 | |||
| 08.20~ | 1200 | G4LF | PSX21 | FR0654V | ||||
| 08.20~ | 1500 | PSX21 | FR0654V | |||||
| 08.20~ | 1500 | G4FL | PSX21 LHD | FR0654V | FT1076 | |||
| 12.23~ | 1500 | G4FL | PSX23 RHD | FR0654V | FP1313 |
| 06.23~ | 1500 | G4FL | CN | FR0654V |
