FiT » ROTOR DISC » FR0805 Feedback Information NEW!

Image Of FR0805
Specification
Type Solid
Outter Ø 297.6
Num. of holes 5
Disc Thickness (Max) 12
Height 64.4
Centering Diameter 62
Pitch Circle Ø 114.3
Drum Ø: 190
Front/Rear Rear
Disc Thickness (Min) 11
Structure Material G3000
Owner Number
Blue Print ADT343236
BREMBO 08.D712.11
NISSHINBO ND1146K
REMSA 61592.00
TOYOTA 42431-58020
TRW DF7857
Copyright © 2025
Years Eng Vol Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
TOYOTA   »   Alphard
11.11~01.15 2400 2AZ-FXE ATH20W FR0749V FP1069 FR0805 FP0239 FT0846
04.08~01.15 2400 2AZ-FE ANH20R FR0749V FP1069 FR0805 FP0239 FT0846
04.08~01.15 3500 2GR-FE GGH20W FR0749V FP1069 FR0805 FP0239 FT0846
04.08~01.15 2400 2AZ-FE ANH20W FR0749VFR0549V FP1069FP1324 FR0805 FP0239 FT0846
06.10~01.15 3500 2GR-FE GGH20L FR0749V FP1069 FR0805 FP0239 FT0846
04.08~01.15 2400 2AZ-FE ANH25W FR0749V FP1069 FR0805 FP0239 FT0846
04.08~01.15 3500 2GR-FE GGH25W FR0749V FP1069 FR0805 FP0239 FT0846
