| Specification | |
|---|---|
| Type | Vented |
| Disc Thickness (Max) | 22 |
| Num. of holes | 5 |
| Height | 46.3 |
| Centering Diameter | 55 |
| Front/Rear | Front |
| Pitch Circle Ø | 100 |
| Outter Ø | 275 |
| Owner | Number |
|---|---|
| ATE | 24.0122-0276.1 |
| BREMBO | 09.A535.21 |
| CAR | 142.1564 |
| DELPHI | BG4277 |
| Fri.tech. | DF1389 |
| HI-Q | SD4001 |
| LYNXauto | BN-1921 |
| Mando | MBC030213 |
| NISSHINBO | ND1052K |
| NK | 2045132 |
| OEM | 19184293 |
| SBS | 18152045132 |
| TEXTAR | 92199300 |
| TOYOTA | 43512-02240 |
| TOYOTA | 43512-02270 |
| TOYOTA | 43512-02280 |
| TOYOTA | 43512-02300 |
| TOYOTA | 43512-12710 |
| TRADEX | TBD1105 |
| TRUSTING | DF1389 |
| TRW | DF6234 |
| Copyright © 2025 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 07.10~07.14 | 1800 | 2ZR-FE | ZRE142 | FR0680V | FP1210 | FR0761 | FT0945FP1354 | |
| 08.10~06.14 | 1600 | 1ZR-FE | ZRE141R | FR0680V | FP1210 | FR0761 | FP1354 | |
| 01.08~08.10 | 1800 | 1ZZ-FE | ZZE142R | FR0680V | FP1210 | FR0761 | FP1354FT0945 | |
| 12.07~07.14 | 1600 | 3ZZ-FE | ZZE141R | FR0680V | FP1210 | FR0761 | FP1354 | |
| 12.13~ | 1600 | 1ZR-FE | ZRE171R | FR0680V | FP1210 | FR0761 | FP1354 | |
| 12.13~ | 1800 | 2ZR-FE | ZRE172L VN | FR0680V | FP1210 | FR0761 | FP1354FT0945 | |
| 05.14~06.19 | 1400 | 1ND-TV | NDE170 | FR0680V | FP1210 | FR0761 | FP1354 | |
| 10.13~07.19 | 1600 | 1ZR-FE | ZRE171L | FR0680V | FP1210 | FR0761 | FP1354FT0945 | |
| 11.08~07.14 | 2000 | 3ZR-FE | ZRE143L | FR0680V | FP1210 | FR0761 | FP1354 | |
| 08.10~11.13 | 1600 | 1ZR-FE | ZRE141L | FR0680V | FP1210 | FR0761 | FP1354FT0945 | |
| 12.13~07.19 | 2000 | 3ZR-FE | ZRE173R | FR0680V | FP1210 | FR0761 | FP1354 | |
| 10.13~07.20 | 2000 | 3ZR-FE | ZRE173L | FR0680V | FP1210 | FR0761 | FT0945FP1354 | |
| 10.13~09.14 | 1800 | 1ZZ-FE | ZZE172L | FR0680V | FP1210 | FR0761 | FT0945FP1354 | |
| 01.08~11.13 | 1300 | 2NZ-FE | ZZE141L | FR0680V | FP1210 | FR0761 | FT0945FP1354 | |
| 01.08~08.10 | 1800 | 1ZZ-FE | ZZE142L | FR0680V | FP1210 | FR0761 | FP1354FT0945 |
| 01.09~04.16 | 1300 | 1NR-FE | NSP110 | FR0680V | FP1210 | FR0824 | FP1354 | |
| 01.09~05.14 | 1400 | 1ND-TV | NLP110 | FR0680V | FP1210 | FP1354 |
| 11.10~04.15 | 1400 | 1ND-TV | NLP121 | FR0680V | FP1210 | FP1354FT0945 | ||
| 11.10~04.15 | 1300 | 1NR-FE | NSP120R | FR0680V | FP1210 | FT0945 | ||
| 11.10~04.15 | 1300 | 1NR-FE | NSP120L | FR0680V | FP1210 | FR0761 | FT0945FP1354 |
| 04.12~ | 1500 | 1NZ-FE | NZE161R | FR0680V | FP1210 | FR0761 | FP1354 | |
| 01.08~08.13 | 2400 | 2AZ-FE | AZE141 | FR0680V | FP1210 | FR0761 | FP1354 | |
| 01.08~08.13 | 1800 | 2ZR-FE | ZRE142L | FR0680V | FP1210 | FT0945 | ||
| 08.13~08.16 | 1800 | 2ZR-FE | ZRE172L | FR1132VFR0680V | FP1210FP1096 | FR1133FR0761 | FT0945FP1572FP1354 | |
| 03.08~11.14 | 1800 | 1ZZ-FE | ZZE142L | FR0680VFR1132V | FP1210FP1571 | FR0761FR1133 | FP1354FP1572 | |
| 07.10~03.14 | 1600 | 1ZR-FE | ZRE141L | FR0680V | FP1210 | FR0761 | FP1354 | |
| 01.09~07.10 | 1600 | 3ZZ-FE | ZZE141L | FR0680V | FP1210 | FR0761 | FP1354FT0945 | |
| 08.07~11.13 | 1500 | 1NZ-FE | NZE141R | FR0680V | FP1210 | FR0761 | FP1354FT0945 | |
| 08.07~03.14 | 2000 | 2C | CE140L | FR0680V | FP1210FP0582 | FR0761 | FP1354FT0945 | |
| 08.10~03.14 | 1600 | 1ZR-FE | ZRE141R | FR0680V | FP1210 | FR0761 | FP1354 |
| 05.07~09.15 | 1500 | 1NZ-FE | NZT260 | FR0680VFR1205V | FP1184FP1210 | FT1208 | ||
| 12.07~12.12 | 2000 | 3ZR-FAE | ZRT261 | FR0680V | FP1210 | FT0945 | ||
| 04.10~03.21 | 1800 | 2ZR-FAE | ZRT260 | FR0680V | FP1210 | FT1208 | ||
| 05.07~04.10 | 1800 | 2ZR-FE | ZRT265 | FR0680V | FP1210 | FT0945 | ||
| 05.07~10.10 | 1800 | 2ZR-FE | ZRT260 | FR0680V | FP1210 | FT1208 | ||
| 04.10~03.21 | 1800 | 2ZR-FAE | ZRT265 | FR0680V | FP1210 | FT0945 |
| 07.07~04.16 | 1500 | 1NZ-FE | NCP110 | FR0680V | FP1210 | FT0945 | ||
| 07.07~04.16 | 1500 | 1NZ-FE | NCP115 | FR0680V | FP1210 | FR0761 | FP1354 | |
| 07.07~08.10 | 1800 | 2ZR-FE | ZSP110 | FR0680V | FP1210 | FT0945 |
| 01.15~ | 1500 | 2NR-FKE | NSP170 | FR0680V | FP1210 | FP1391 | FT0796 | |
| 01.15~ | 1500 | 1NZ-FXE | NHP170 | FR0680V | FP1210 | FP1391 | FT0796 | |
| 06.15~ | 1500 | 1NZFE | NCP175G | FR0680V | FP1210 | FP1391 | FT0796 |
| 11.10~05.14 | 1500 | 1NZ-FE | NCP125 | FR0680V | FP1068 | FT0945 | ||
| 11.10~05.14 | 1500 | 1NZ-FE | NCP120 | FR0680V | FP1068 | FT0945 | ||
| 12.08~05.14 | 1300 | 1NR-FE | NSP120 | FR0680V | FP1068 | FT0945 | ||
| 11.10~ | 1300 | 1NR-FE | NSP122 | FR0680V | FP1068 | FT0945 |
| 11.10~07.16 | 1500 | 1NZ-FE | NCP120X | FR0680V | FP1068 | FR0761 | FT0945FP1354 | |
| 11.10~07.16 | 1500 | 1NZ-FE | NCP125X | FR0680V | FP1068 | FT0945 | ||
| 11.10~07.16 | 1300 | 1NR-FE | NSP120X | FR0680V | FP1068 | FT0945 |
