| Specification | |
|---|---|
| Length-1 | 133.2 |
| Width-1 | 52.5 |
| Thickness-1 | 14.8 |
| Pcs In Set | 4 |
| Owner | Number |
|---|---|
| AKEBONO | A-261K |
| AKEBONO | A-SM261K |
| AKEBONO | AN-261K |
| BENDIX AUS | DB1137 |
| CTR | CKT-111 |
| CTR | GK1124 |
| DJ PARTS | BP1401 |
| FBL | AFP138 |
| FMSI | D604-7485 |
| HITACHI | NDP140 |
| ICER | 182087 |
| KASHIYAMA | D2067 |
| KASHIYAMA | D206702 |
| KASHIYAMA | D2153 |
| KASHIYAMA | D2153TX |
| LYNXauto | BD-7618 |
| Miyaco | MD018 |
| NISSHINBO | NP1090 |
| NISSHINBO | PF-1157 |
| NISSHINBO | PF-1157-2 |
| SANGSIN | SP 1141 |
| SANGSIN | SP1421 |
| SUMITOMO | SN249 |
| SUMITOMO | SX249 |
| TOKICO | TN212 |
| TOYOTA | 04465-30040 |
| TOYOTA | 04465-30050 |
| TOYOTA | 04465-30060 |
| TOYOTA | 04465-30100 |
| TOYOTA | 04465-30170 |
| TOYOTA | 04465-34010 |
| TOYOTA | 04465-34030 |
| TOYOTA | 04465-YZZ52 |
| TOYOTA | 04491-30180 |
| TOYOTA | 04491-30190 |
| TOYOTA | 04491-30191 |
| TOYOTA | 04491-30200 |
| TOYOTA | 04491-30220 |
| TOYOTA | 04491-30230 |
| TOYOTA | 04491-30231 |
| TOYOTA | 04491-30240 |
| TOYOTA | 04491-30250 |
| TOYOTA | 04491-30260 |
| TOYOTA | 04491-30270 |
| TOYOTA | 04491-30300 |
| TOYOTA | 04491-30310 |
| TOYOTA | 04491-30320 |
| TOYOTA | 04491-34020 |
| TOYOTA | AY040-TY003 |
| TOYOTA | AY040-TY004 |
| TOYOTA | V9115-0019 |
| TOYOTA | V9118-1021 |
| TOYOTA | V9118-3021 |
| TOYOTA | V9118-A021 |
| TOYOTA | V9118-A062 |
| Copyright © 2025 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.87~04.99 | 2000 | GS130G | FP0604 | FT0764 | ||||
| 09.87~12.95 | 2000 | YS130 | FT1163FP0604 | FT1172 | ||||
| 08.90~12.95 | 2500 | 1JZ-GE | JZS131 | FR0956V | FP0604 | FP0304 | ||
| 12.91~12.95 | 2000 | YS130 | FP0604 | FT0764 | ||||
| 09.87~04.99 | 2000 | GS130H | FP0604 | FT0764 | ||||
| 09.87~12.95 | 2000 | 1G-GZE | GS131H | FP0604 | FP0304 | |||
| 10.91~12.95 | 3000 | 2JZ-GE | JZS135 | FP0604 | FR0592 | FP0304 | ||
| 08.93~09.95 | 2400 | 2L-TE | LS131 | FP0604 | FP0304 | |||
| 09.87~10.91 | 3000 | 7M-GE | MS137 | FP0604 | FP0304 | |||
| 09.87~04.99 | 2000 | MS130 | FP0604 | FT0764 | ||||
| 09.87~12.95 | 2000 | GS141 | FP0604 | FP0304 | ||||
| 09.87~09.94 | 2400 | 2L | LS136V | FP0604 | FT0764 | |||
| 09.88~12.95 | 2000 | 1G-FE | GS130 | FR0956V | FP0604 | FT0764FP0304 | ||
| 01.91~12.95 | 2400 | 2L-THE | LS141 | FR0595V | FP0604 | FP0304 | FT1156 | |
| 09.87~10.91 | 3000 | 7M-GE | MS135 | FR0956V | FP0604 | FP0304 | ||
| 08.89~12.95 | 2000 | 1G-FE | GS131R | FR0956V | FP0604 | FP0304 | FT1156 | |
| 08.93~04.99 | 2400 | 2L-TE | LS130W | FR0956V | FP0604 | FT0764 | ||
| 08.90~04.99 | 2500 | 1JZ-GE | JZS130G | FR0595V | FP0604 | FT0764 | ||
| 01.88~11.01 | 3000 | 2JZ-GE | JZS133R | FR0595V | FP0604 | FP0304 | FT1156 | |
| 10.91~12.95 | 3000 | 2JZ-GE | JZS133L | FR0595V | FP0604 | FP0304 | FT1156 | |
| 10.91~12.95 | 3000 | 2JZ-GE | JZS133 | FR0595V | FP0604 | FP0304 | FT1156 | |
| 08.93~07.95 | 2000 | 1G-FE | GS141 | FR0595V | FP0604 | FP0304 | FT1156 | |
| 08.89~10.91 | 2400 | 2L-THE | LS131 | FR0956V | FP0604 | FP0304 | FT1156 | |
| 10.91~08.93 | 2400 | 2L-THE | LS131H | FR0956V | FP0604 | FP0304 | FT1156 | |
| 08.89~10.91 | 4000 | 1UZ-FE | UZS131 | FR0595V | FP0604 | FP0304 | ||
| 01.88~12.95 | 2000 | 1G-FE | GS131 | FR0956V | FP0604 | FP0304 | FT1156 | |
| 10.91~12.95 | 2000 | 1G-FE | GS131H | FR0956V | FP0604 | |||
| 12.95~09.98 | 2000 | 1G-FE | GS130W | FR0956V | FP0604 | FT0764 | ||
| 08.89~04.99 | 2000 | 1G-FE | GS136V | FR0956V | FP0604 | FT0764 |
| 10.91~08.95 | 3000 | 2JZ-GE | JZS143 | FP0604 | FR0592 | FP0304 | ||
| 10.91~08.95 | 3000 | 2JZ-GE | JZS145 | FP0604 | FR0592 | FP0304 | ||
| 10.91~08.95 | 2500 | 1JZ-GE | JZS141 | FR0595V | FP0604 | FP0304 | FT1156 |
| 09.93~07.98 | 2700 | 3RZ-F | RCK10 | FP0604 | FT1184 | |||
| 08.94~07.98 | 3400 | 5VZ-FE | VCK11L | FP0604 | FT1184FT2131FT1173 | |||
| 01.92~01.98 | 3000 | 3VZ-E | VCK10 | FP0604FP0562 | FT2131FT1173 |
