| Specification | |
|---|---|
| Type | Vented |
| Disc Thickness (Max) | 30 |
| Num. of holes | 6 |
| Height | 46.5 |
| Centering Diameter | 100 |
| Front/Rear | Front |
| Pitch Circle Ø | 124 |
| Outter Ø | 278.6 |
| Owner | Number |
|---|---|
| BOSCH | 0 986 AB9 710 |
| DJ PARTS | BD1955 |
| ISUZU | 5861304870 |
| ISUZU | 5861328160 |
| NISSAN | 40206-3XA0A |
| NISSAN | 40206-VW000 |
| NISSAN | 40206-VW601 |
| NISSHINBO | ND2037K |
| TOKICO | TY151 |
| TRADEX | TBD1138 |
| TRW | DF7220 |
| Copyright © 2025 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 04.01~09.07 | 2400 | KA24DE | CQGE25 | FR0552V | FP1191 | FT2130 | ||
| 04.01~06.12 | 3000 | ZD30DD# | CWGE25 | FR0552V | FP1191 | FT2130 | ||
| 11.01~09.07 | 2400 | KA24DE | QGE25 | FR0552V | FP1191 | FT2130 | ||
| 04.01~06.12 | 3000 | ZD30DD# | VWE25 | FR0552V | FP1191 | FT2130 | ||
| 09.02~06.12 | 3000 | ZD30DDTi | CWMGE25 | FR0552V | FP1191 | FT2130 | ||
| 09.07~06.12 | 2500 | QR25DE | SGE25 | FR0552V | FP1191 | FT2130 | ||
| 04.01~06.12 | 3000 | ZD30DD# | DWMGE25 | FR0552V | FP1191 | FT2130 | ||
| 04.01~09.07 | 2000 | KA20DE | VPE25 | FR0552V | FP1191 | FT2130 | ||
| 09.07~06.12 | 2500 | QR25DE | SE25 | FR0552V | FP1191 | FT2130 | ||
| 09.07~06.12 | 2500 | QR25DE | DSGE25 | FR0552V | FP1191 | FT2130 | ||
| 04.01~06.12 | 3000 | ZD30DD# | VWME25 | FR0552V | FP1191 | FT2130 | ||
| 09.07~06.12 | 2000 | QR20DE | VRE25 | FR0552V | FP1191 | FT2130 | ||
| 04.01~06.12 | 3000 | ZD30DD# | DWGE25 | FR0552V | FP1191 | FT2130 | ||
| 09.07~06.12 | 2500 | QR25DE | CSGE25 | FR0552V | FP1191 | FT2130 | ||
| 05.03~09.07 | 2400 | KA24DE | QE25 | FR0552V | FP1191 | FT2130 | ||
| 04.01~09.07 | 2400 | KA24DE | DQGE25 | FR0552V | FP1191 | FT2130 |
| 06.12~ | 2500 | YD25DDTI | E26 | FR0552V | FP1191 | FT2130FT2137 | ||
| 06.12~ | 2500 | QR25DE | E26 | FR0552V | FP1191 | FT2130FT2137 | ||
| 06.12~ | 2000 | QR20DE | E26 | FR0552V | FP1191 | FT2130FT2137 |
| 06.12~ | 2500 | QR25DE | CS4E26 | FR0552V | FP1191 | FT2130FT2137 | ||
| 06.12~ | 2500 | YD25DDTI | CW4E26 | FR0552V | FP1191 | FT2130FT2137 | ||
| 06.12~ | 2500 | YD25DDTI | CW8E26 | FR0552V | FP1191 | FT2130FT2137 | ||
| 06.12~ | 2500 | QR25DE | KS2E26 | FR0552V | FP1191 | FT2130FT2137 | ||
| 06.12~ | 2500 | QR25DE | KS4E26 | FR0552V | FP1191 | FT2130FT2137 | ||
| 06.12~ | 2500 | YD25DDTI | VW2E26 | FR0552V | FP1191 | FT2130 | ||
| 06.12~ | 2500 | YD25DDTI | VW6E26 | FR0552V | FP1191 | FT2130FT2137 | ||
| 12.12~ | 2500 | QR25DE | DS4E26 | FR0552V | FP1191 | FT2130FT2137 | ||
| 12.12~ | 2500 | YD25DDTI | DW4E26 | FR0552V | FP1191 | FT2130FT2137 | ||
| 06.12~ | 2000 | QR20DE | VR2E26 | FR0552V | FP1191 | FT2130 |
| 01.00~11.12 | 3000 | ZD30DD | E25 | FR0552V | FP1191 | FT2130 | ||
| 05.01~08.07 | 2400 | KA24DE | E25 | FR0552V | FP1191 | FT2130 | ||
| 08.07~11.12 | 2500 | QR25DE | E25 | FR0552V | FP1191 | FT2130 | ||
| 01.01~11.12 | 3000 | ZD30DDTi | E25 | FR0552V | FP1191 | FT2130 |
| 06.12~ | 2500 | YD25DDTI | E26 | FR0552V | FP1191 | FT2130 | ||
| 06.12~ | 2500 | QR25DE | E26 | FR0552V | FP1191 | FT2130 | ||
| 09.17~ | 2500 | QR25DE | E26 GL | FR0552V | FP1191 | FT2130 |
| 06.07~ | 3000 | ZD30DDTi | SZ2F24 | FR0552V | FP1191 | FT3297 | FT2148 | |
| 06.07~ | 3000 | ZD30DDTi | SZ5F24 | FR0552V | FP1191 | FT2131FT1173 | ||
| 06.07~10.11 | 3000 | ZD30DDTi | SZ1F24 | FR0552V | FP1191 | FT3297 | FT2148 | |
| 06.07~ | 2000 | QR20DE | SQ2F24 | FR0552V | FP1191 | FT2131FT1173FT3297 | FT2148 |
| 04.01~09.07 | 2000 | KA20DE | JVPE25 | FR0552V | FP1191 | FT2130 | ||
| 12.01~09.07 | 2400 | KA24DE | JQGE25 | FR0552V | FP1191 | FT2130 | ||
| 06.03~09.07 | 2400 | KA24DE | JQE25 | FR0552V | FP1191 | FT2130 | ||
| 09.07~07.12 | 2000 | QR20DE | JVRE25 | FR0552V | FP1191 | FT2130 | ||
| 05.01~09.07 | 2400 | KA24DE | JCQGE25 | FR0552V | FP1191 | FT2130 | ||
| 05.01~09.07 | 2400 | KA24DE | JDQGE25 | FR0552V | FP1191 | FT2130 | ||
| 09.07~07.12 | 2500 | QR25DE | JSE25 | FR0552V | FP1191 | FT2130 | ||
| 05.01~12.10 | 3000 | ZD30DD# | JDWGE25 | FR0552V | FP1191 | FT2130 | ||
| 09.07~07.12 | 2500 | QR25DE | JSGE25 | FR0552V | FP1191 | FT2130 | ||
| 05.01~07.12 | 3000 | ZD30DD# | JVWME25 | FR0552V | FP1191 | FT2130 | ||
| 05.01~07.12 | 3000 | ZD30DD# | JCWGE25 | FR0552V | FP1191 | FT2130 | ||
| 09.07~07.12 | 2500 | QR25DE | JDSGE25 | FR0552V | FP1191 | FT2130 | ||
| 05.01~07.12 | 3000 | ZD30DD# | JDWMGE25 | FR0552V | FP1191 | FT2130 | ||
| 05.01~07.12 | 3000 | ZD30DD# | JCWMGE25 | FR0552V | FP1191 | FT2130 | ||
| 07.12~ | 2500 | QR25DE | JCS4E26 | FR0552V | FP1191 | FT2130FT2137 | ||
| 07.12~ | 2500 | YD25DDTI | JCW4E26 | FR0552V | FP1191 | FT2130FT2137 | ||
| 07.12~ | 2000 | QR20DE | JVR2E26 | FR0552V | FP1191 | FT2130 | ||
| 07.12~ | 2500 | YD25DDTI | JVW2E26 | FR0552V | FP1191 | FT2130 |
