| Specification | |
|---|---|
| Type | Solid |
| Outter Ø | 302 |
| Num. of holes | 5 |
| Disc Thickness (Max) | 10 |
| Height | 60.5 |
| Centering Diameter | 80 |
| Pitch Circle Ø | 114.3 |
| Drum Ø: | 168 |
| Front/Rear | Rear |
| Disc Thickness (Min) | 8.4 |
| Structure Material | G3000 |
| Owner | Number |
|---|---|
| ATE | 24.0110-0360.1 |
| Blue Print | ADA104318 |
| CAR | 142.1478 |
| CHRYSLER | 04743 999AA |
| CHRYSLER | 2AMV3 999AA |
| CHRYSLER | 4615A010 |
| CHRYSLER | 4615A121 |
| DELPHI | BG4169 |
| Fri.tech. | DF1412 |
| INTERBRAKE | JP051P |
| LYNXauto | BN-1380 |
| MINTEX | MDC1930 |
| MITSUBISHI | 4615A010 |
| MITSUBISHI | 4615A121 |
| MITSUBISHI | 4615A193 |
| PAGID | 54773PRO |
| Peugeot / Citroen | 16 062 920 80 |
| Peugeot / Citroen | 16 116 678 80 |
| REMSA | 61290.00 |
| ROADHOUSE | 61290.00 |
| TEXTAR | 92177303 |
| TRUSTING | DF1412 |
| TRW | DF6326 |
| WOKING | D61290.00 |
| Copyright © 2024 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 03.07~12.10 | 2000 | FR0512 | ||||||
| 01.07~12.14 | 2400 | ED3 | JSZS41 | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 09.06~12.10 | 2700 | EER | JS | FR0321V | FP0866 | FR0512FR0477 | FP1037FP0868 | FT3183 |
| 01.08~12.17 | 2000 | ECE | MK74 | FP0866 | FR0512 | FP1037 | FT3183 | |
| 01.07~12.17 | 2400 | ED3 | MKJL74 | FR0321V | FP0866 | FR0512FR0477 | FP0868FP1037 | FT3183 |
| 09.05~09.12 | 2400 | 4B12 | CW5W | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 06.09~09.12 | 2000 | 4B11 | CW4W RHD | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 09.05~09.12 | 2400 | 4B12 | CW5W JPN | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 11.06~04.12 | 3000 | 6B31 | CW6W | FR0321VFR0513V | FP0866FP0530 | FR0514FR0512 | FP0868 | FT0086FT3183 |
| 04.06~10.12 | 2000 | BSY | CW8W | FR0513V | FP0530 | FR0514FR0512 | FP0868 | FT0086FT3183 |
| 10.09~10.12 | 2000 | 4B11 | CW4W EU LHD | FR0513V | FP0530 | FR0512 | FP0868 | FT3183 |
| 05.10~05.13 | 2000 | 4B11 | GA2W | FR0321V | FP0866 | FR0512FR0671 | FP5151FP0868 | FT3183 |
| 08.10~05.13 | 1600 | 4A92 | GA1W | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 |
| 05.10~02.13 | 1800 | 4B10 | GA3W | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 |
| 04.10~06.12 | 1800 | 4N13 | GA6W | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 |
| 02.10~10.12 | 1800 | 4B10 | GA3W | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 10.11~09.12 | 1800 | 4J10 | GA4W | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 |
| 01.07~12.17 | 2000 | 4B11 | CY4A | FR0476VFR0321VFR0513V | FP0866FP0530 | FR0477FR0512FR0514 | FP0868FP1037 | FT3183 |
| 11.08~02.12 | 1800 | 4J10 | CY3A | FR0476VFR0321V | FP0866 | FR0512FR0477 | FP0868FT0924FP1037 | FT3183 |
| 12.08~03.15 | 2000 | 4B11-T | CX4A | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 11.08~03.15 | 1800 | 4B10 | CX3A | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 06.07~12.14 | 2400 | ED3 | FP0866 | FR0512 | FP1037 | |||
| 01.07~12.10 | 2700 | EER | JSDP41 | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 06.06~11.12 | 2000 | ECN | PM_H49 | FR0321VFR0476V | FP0866 | FR0512 | FP0868FT0919 | FT3183 |
| 05.06~06.09 | 2000 | ECD | PMBH49 | FR0321V | FP0866 | FR0512 | FP0868 | FT3183 |
| 10.06~11.12 | 2400 | ED3 | PM | FR0476V | FP0866 | FR0512FR0477 | FP1037FP0868 | FT3183 |
| 04.12~04.17 | 2000 | 4B11 | FR0321V | FP0866 | FR0671FR0512 | FP5151FP0868 | FT3183 | |
| 04.12~04.17 | 1600 | 4A92 | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 | ||
| 04.12~04.17 | 1800 | 4N13 | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 |
| 04.12~10.12 | 2000 | 4B11 | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 | |
| 04.12~10.12 | 1600 | 4A92 | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 | |
| 04.12~10.12 | 1600 | DV6C | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 | |
| 04.12~10.12 | 1800 | 4N13 | FR0321V | FP0866 | FR0512FR0671 | FP0868FP5151 | FT3183 |
| 12.18~11.22 | 2000 | 4J11 | GA9W | FR0321V | FP0866 | FR0512 | FP0868 | |
| 08.12~11.22 | 1600 | 4A92 | GA1W | FR0321V | FP0866 | FR0512 | FP0868 | |
| 08.12~11.19 | 2000 | 4B11 | GA2W | FR0321V | FP0866 | FR0512 | FP0868 |
