| Specification | |
|---|---|
| Type | Vented |
| Outter Ø | 300 |
| Num. of holes | 5 |
| Disc Thickness (Max) | 25 |
| Height | 48.5 |
| Centering Diameter | 72 |
| Pitch Circle Ø | 114.3 |
| Front/Rear | Front |
| Drum Ø: | 140 |
| Owner | Number |
|---|---|
| APEC | DSK2211 |
| ATE | 24.0125-0170.1 |
| Blue Print | ADM543105 |
| BOSCH | 0 986 479 183 |
| BREMBO | 09.9468.20 |
| BREMBO | FD.192.000 |
| BREMBO | FS.192.000 |
| CAR | 142.1267 |
| CIFAM | 800-730 |
| DELPHI | BG3928 |
| FERODO | DDF1312 |
| Fri.tech. | DF988 |
| GIRLING | 6043851 |
| HERTH+BUSS | J3303084 |
| INTERBRAKE | MX021V |
| LPR | M5006V |
| LUCAS | DF4385 |
| LYNXauto | BN-1069 |
| MAZDA | BP6Y3325XD |
| MAZDA | BP6Y3325XE |
| MAZDA | BP6Y3325XF |
| MAZDA | C26Y3325X |
| MAZDA | C26Y3325XA |
| MAZDA | C26Y3325XB |
| MAZDA | C26Y3325XD |
| Metelli | 23-0730 |
| MINTEX | MDC1988 |
| NECTO | WN1318 |
| NIPPARTS | J3303084 |
| NISSHINBO | ND5002K |
| OEM | C26Y3325XB |
| OEM | C26Y3325XC |
| PAGID | 54304 |
| PILENGA | V523 |
| QH | BDC5492 |
| REMSA | 6672.10 |
| ROADHOUSE | 6672.10 |
| SBS | 1815203253 |
| TEXTAR | 92130400 |
| TRUSTING | DF988 |
| TRW | DF4385 |
| WOKING | D6672.10 |
| ZIMMERMANN | 370.3077.00 |
| Copyright © 2025 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 02.05~07.10 | 2000 | FS7# | CR19 | FR0306V | FP1230 | FR0723 | FP0973 | |
| 12.04~08.07 | 2300 | L3-VE | CR3W | FR0305VFR0306V | FP1230 | FR0723FR0479 | FP0973 | |
| 08.07~07.10 | 2300 | L3-VE | CR3W | FR0306V | FP1230 | FR0723 | FP0973 |
| 01.03~03.09 | 2000 | LF# | BK HB | FR0306V | FP1230 | FR0483 | FP0973 | |
| 01.03~03.09 | 2000 | LF-VE | JM6BK SDN | FR0306V | FP1230 | FR0483 | FP0973 | |
| 01.03~08.11 | 2300 | L3-VE | BK | FR0306V | FR0483 | FP0973 | ||
| 03.06~03.09 | 2000 | RF-T | BK | FR0306V | FR0483 | FP0973 | ||
| 06.03~07.06 | 2000 | LF# | BK HB | FR0306V | FP1230 | FR0483 | FP0973FT5253FT1278 | |
| 03.06~03.09 | 2000 | LF-VE | AEBA11 SDN RU | FR0306V | FP1230 | FR0483 | FP0973 | |
| 11.08~11.11 | 2000 | LF# | JMZBL HB | FR0306V | FP1230 | FR0483 | FP0973 |
| 05.13~03.18 | 2000 | PE-VPS | CC1071 RHD | FR0306V | FP1230 | FR0723 | FP0973 | |
| 06.09~05.13 | 2000 | LF-VDS | CCEFW | FR0306V | FP1230 | FR0723 | FP0973 | |
| 07.08~05.13 | 2000 | LF-VD | CCEFW | FR0306V | FP1230 | FR0723 | FP0973 | |
| 07.08~05.13 | 2300 | L3-VE | CC3FW | FR0306V | FP1230 | FR0723 | FP0973 | |
| 07.08~05.13 | 2000 | LF-VD | CCEAW | FR0306V | FP1230 | FR0723 | FP0973 | |
| 05.13~03.18 | 2000 | PE-VPS | CCFFW JPN | FR0306V | FP1230 | FR0723 | FP0973 |
| 10.10~08.17 | 2000 | PE-VPS | CW | FR0306VFR0305V | FP1230 | FR0723FR0483 | FP0973 | |
| 02.05~06.10 | 2000 | LFF7 | CR | FR0306VFR0305V | FP1230 | FR0723FR0483 | FP0973 | |
| 02.05~10.10 | 1800 | L823 | CR | FR0305VFR0306V | FP1230 | FR0483FR0723 | FP0973 | |
| 02.05~06.10 | 2000 | RF7J | CR | FR0305VFR0306V | FP1230 | FR0483FR0723 | FP0973 | |
| 09.04~03.08 | 2300 | L3-VE | CR | FR0305VFR0306V | FP1230 | FR0483FR0723 | FP0973 | |
| 06.10~08.17 | 1800 | L8 | CW | FR0306VFR0305V | FP1230 | FR0483FR0723 | FP0973 | |
| 06.10~08.17 | 2000 | LF-VE | CW | FR0306VFR0305V | FP1230 | FR0483FR0723 | FP0973 | |
| 06.10~08.17 | 2000 | LF5H | CW | FR0306VFR0305V | FP1230 | FR0483FR0723 | FP0973 | |
| 06.10~08.17 | 2500 | L5-VE | CW | FR0306V | FP1230 | FR0723 | FP0973 | |
| 06.10~08.17 | 1600 | Y6 | CW | FR0306VFR0305V | FP1230 | FR0483FR0723 | FP0973 | |
| 03.08~10.10 | 2300 | L3-V# | AUCV02 US | FR0305VFR0306V | FP1230 | FR0723 | FP0973 | |
| 02.05~06.10 | 2000 | LFF7 | CR19 EU LHD | FR0305VFR0306V | FP1230 | FR0483FR0723 | FP0973 |
| 06.06~05.09 | 2300 | L3-VDT | BK3P | FR0306V | FP0213FP1230 | FR0483 | FP0973 | |
| 10.03~06.09 | 2300 | L3-VE | BK3P | FR0306V | FP1230 | FR0483 | FP0973 |
| 12.10~05.15 | 1500 | ZY-VE | DE 5DR HB | FR1029VFR0306V | FP0054FP0028 | FT1089 | ||
| 12.10~05.15 | 1500 | ZY-VE | DE SDN | FR1029VFR0306V | FP0054FP0028 | FT1089 |
