| Specification | |
|---|---|
| Type | Vented |
| Outter Ø | 304 |
| Num. of holes | 5 |
| Disc Thickness (Max) | 28 |
| Disc Thickness (Min) | 26 |
| Height | 48.1 |
| Centering Diameter | 71 |
| Pitch Circle Ø | 108 |
| Drum Ø: | 133 |
| Structure Material | G3000 |
| Owner | Number |
|---|---|
| AKEBONO | BN-0473E |
| ATE | 24012802691 |
| BOSCH | 0986479A89 |
| BREMBO | 09.C133.10 |
| BREMBO | 09C13311 |
| CITROEN | 4249.K1 |
| LYNXauto | BN-1382 |
| MINTEX | MDC2293 |
| PEUGEOT | 4249 K1 |
| PEUGEOT | 4249.93 |
| PEUGEOT | 4249A3 |
| Peugeot / Citroen | 96 863 247 80 |
| REMSA | 61472.10 |
| TEXTAR | 92232305 |
| TOYOTA | SU001-A9002 |
| TRW | DF 6419 |
| Copyright © 2025 | |
| Years | Eng Vol | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.10~09.18 | 1600 | EP6CDT 156PH | 4-Sedan | FR1380VFR1023V | FP1306FP1966E | FR0982 | FP0973FP2338 | |
| 08.14~11.18 | 1600 | EP6FDT | 4-Sedan | FR1380V | FP1306 | FR0982 | FP0973FP2338 | |
| 08.14~11.18 | 1600 | DV6FC | 4-Sedan | FR1023VFR1380V | FP1966E | FR0982 | FP0973 | |
| 11.10~09.18 | 1600 | DV6C | 4-Sedan | FR1023VFR1380V | FP1966EFP1306 | FR0982 | FP0973FP2338 | |
| 11.10~09.18 | 1600 | EP6CDT | 8D | FR1380V | FP1306 | FR0982 | FP0973 | |
| 03.18~ | 1600 | EP6FADTXD | 8D | FR1380V | FP2313 | FR1169 | FP2312 | |
| 03.18~ | 2000 | DW10FC | R8 | FR1380V | FP2313 | FR1022FR1169 | FP2312FP2311 | |
| 03.18~ | 1600 | EP6FADTXD 180 | F35GFT RHD 5DR HB | FR1380V | FP2313 | FR1022FR1169 | FP2311FP2312 | |
| 06.20~ | 1200 | EB2ADT | R8 | FR1380V | FP2313 | FR1022FR1169 | FP2312FP2311 | |
| 03.18~ | 1500 | DV5RC | R8 | FR1380V | FP2313 | FR1022FR1169 | FP2312FP2311 | |
| 03.18~ | 1600 | EP6F# | R8 | FR1380V | FP2313 | FR1022FR1169 | FP2312FP2311 | |
| 08.14~06.18 | 1600 | EP6CDT M 163PH | 4-Sedan | FR1380VFR1023V | FP1306FP1966E | FR0982 | FP2338FP0973 |
| 11.10~09.18 | 1600 | EP6CDT 156PH | 5-Hatchback | FR1380VFR1023V | FP1306FP1966E | FR0982 | FP0973FP2338 | |
| 11.10~11.18 | 1600 | EP6FDT | 5-Hatchback | FR1380VFR1023V | FP1306 | FR0982 | FP0973FP2338 | |
| 11.10~11.18 | 1600 | DV6C | 5-Hatchback | FR1380VFR1023V | FP1306 | FR0982 | FP0973FP2338 | |
| 10.18~ | 1500 | DV5RC | FC WGN EU LHD | FR1380V | FP2313 | FR1169FR1022 | FP2312FP2311 |
| 05.16~ | 1600 | DV6FC | 5-Crossover | FR1380V | FP2313 | FR1169 | FP2312 | |
| 06.16~ | 1200 | EB2DTS | 5-Crossover | FR1380V | FP2313 | FR1022FR1169 | FP2311FP2312 | |
| 05.16~ | 2000 | DW10FD | 5-Crossover | FR1380V | FP2313 | FR1022 | FP2311 | |
| 01.17~ | 1500 | DV5RC | 5DR SUV | FR1380V | FP2313 | FR1022 | FP2311 | |
| 05.16~09.20 | 1600 | EP6FADTXD | M45GFR 5DR SUV RHD | FR1380V | FP2313 | FR1022 | FP2311 | |
| 09.20~ | 1600 | EP6FDT | P84E LHD | FR1380V | FP2313 | FR1022 | FP2311 | |
| 05.16~11.20 | 1600 | EP6FDT | P84E RHD | FR1380V | FP2313 | FR1169FR1022 | FP2312FP2311 |
| 06.14~05.21 | 1600 | EP6FDT | 5-Hatchback | FR1380V | FP2313 | FR1022 | FP2312 | |
| 09.13~12.17 | 1600 | DV6FD | 5DR HB | FR1380VFR1023V | FP2120FP2310FP2313 | FR0988 | FP1890FP2312 | |
| 04.14~05.21 | 2000 | DW10FD | T9 | FR1380V | FP2313 | FR1169 | FP2312 |
| 09.18~ | 1500 | DV5RC | K9 | FR1380V | FP2313 | FR1169 | FP2312 | |
| 09.18~ | 1500 | DV5RD | K9 | FR1380V | FP2313 | FR1169 | FP2312 | |
| 09.18~ | 1600 | DV6DTED | K9 | FR1380V | FP2313 | FR1169 | FP2312 | |
| 09.18~ | 1200 | EB2ADT | K9 | FR1380VFR1023V | FP2313FP2310 | FR1169 | FP2312 | |
| 09.18~ | 1600 | EC5F | Fourgon | FR1380V | FP2313 | FR1169 | FP2312 |
| 12.16~ | 1200 | EB2DTS | 5DR SUV | FR1380V | FP2313 | FR1022 | FP2311 | |
| 12.16~ | 5DR SUV | FR1380V | FP2313 | FR1022 | FP2311 | |||
| 01.18~ | 1500 | DV5RC | 5DR SUV | FR1380V | FP2313 | FR1022 | FP2311 | |
| 12.16~ | 1600 | EP6F# | 5DR SUV | FR1380V | FP2313 | FR1022 | FP2311 | |
| 12.16~ | 1600 | DV6F# | 5DR SUV | FR1380V | FP2313 | FR1022 | FP2311 | |
| 12.16~ | 1200 | EB2ADTS | 5DR SUV | FR1380V | FR1022 | FP2311 | ||
| 09.16~11.20 | 1600 | EP6FADTXD 180 | 5DR SUV | FR1380V | FP2313 | FR1022 | FP2311 | |
| 09.16~11.20 | 1600 | EP6FDT | 5DR SUV | FR1380V | FP2313 | FR1022 | FP2311 | |
| 12.16~ | 2000 | DW10F# | 5DR SUV | FR1380V | FP2313 | FR1022 | FP2311 |
| 07.22~ | 1200 | EB2ADTS | P54 | FR1380V | FR1169 | FP2312 | ||
| 07.22~ | 1600 | EP6FADTXHP | P54 | FR1380V | FR1022FR1169 | FP2311FP2312 |
| 07.14~ | 1600 | EP6FDT | B78 | FR1380V | FP2313 | FR1022 | FP2311 | |
| 02.13~ | 1600 | DV6C | B78 | FR1023VFR1380V | FP2313 | FR1022FR1169 | FP2311FP2312 |
| 11.18~ | 1200 | EB2ADTS | C84 | FR1380V | FR1022 | FP2311 | ||
| 11.18~ | 1500 | DV5RC | C84 | FR1380V | FP2313 | FR1022 | FP2311 | |
| 01.22~ | 1600 | EP6FDT | SUV | FR1380V | FR1022 | FP2311 | ||
| 04.17~01.22 | 1600 | EP6FDT | SUV | FR1380V | FP2313 | FR1022 | FP2311 | |
| 04.17~01.22 | 1600 | EP6FADTXD | SUV | FR1380V | FP2313 | FR1022 | FP2311 |
| 06.18~ | 1500 | YHZ (DV5RC) | K9 | FR1380V | FP2313 | FR1169 | FP2312 | |
| 06.18~ | 1200 | EB2DT | M/VAN | FR1380VFR1023V | FP2310 | FR1169 | FP2312 | |
| 06.18~ | 1600 | DV6FD | M/VAN | FR1023VFR1380V | FP2310 | FR1169 | FP2312 |
| 03.17~ | 1600 | EP6FDT | X74 | FR1380V | FP2313 | FR1022 | FP2311 | |
| 03.17~ | 1200 | EB2ADTS | X74 | FR1380V | FP2313 | FR1022 | FP2311 | |
| 03.17~ | 1500 | DV5RC | X74 | FR1380V | FP2313 | FR1022 | FP2311 | |
| 03.17~ | 2000 | DW10FC | X74 | FR1380V | FP2313 | FR1022 | FP2311 |
| 07.17~ | 1200 | F12XHT (EB2ADTS) | A18 | FR1380V | FP2313 | FR1169FR1022 | FP2312FP2311 | |
| 03.18~ | 1500 | D15DT# | A18 | FR1380V | FP2313 | FR1169FR1022 | FP2312FP2311 | |
| 07.17~ | 1600 | B16DTH | A18 | FR1380V | FP2313 | FR1169FR1022 | FP2312FP2311 | |
| 01.18~ | 2000 | D20DTH | A18 | FR1380V | FP2313 | FR1169FR1022 | FP2312FP2311 | |
| 09.18~ | 1600 | D16XHT | A18 | FR1380V | FP2313 | FR1169FR1022 | FP2312FP2311 |
